Valvole Pompe Rubinetti Saracinesche
catalog Cod. art: 001

SAFETY

Disconnector reduced pressure zone threaded ends

Uses:
Construction:

bronze body – brass ½” coupling, check valve, discharge valve seat – asbestos free gasket – CuZn40Pb2 brass M/F ¼” mini-valve – NORYL check valve seats and discharge device – AISI 302 stainless steel check valve and discharge valve springs – PTFE compensator – neoprene and nylon membrane – silicon rubber gaskets – polypropylene discharge house holder – NBR O-ring – AISI 304 stainless steel bolts and screws – brass ø ½” body – UNI ISO 228/1 threaded ends – approved to UNI EN 12729 standards.

Diameters:

½” ÷ 2” Temperatura massima 65°C Pressione massima in ingresso 10 bar

Applications:

eliminates all possible causes of potentially contaminated fluid flowing back from a branch of the main network, disconnecting the line in case of a potential risk.
